Specifications
173.4 inches long, 8.1 inches of ground clearance, 27.2 cubic feet of cargo room and 26 MPG combined, with one 2.0-liter turbo across all six trims.
The 2026 Jeep Compass measures 173.4 inches long on a 103.8-inch wheelbase, weighs 3,620 pounds in most trims, carries 27.2 cubic feet behind the second row and returns 26 MPG combined. One 2.0-liter turbo and one eight-speed automatic serve all six trims, so most of the numbers below are lineup-wide rather than trim-specific.
On commercial corridors laid out for sedans and in summer lots striped at an angle, the specifications that settle a purchase here are the small ones: overall length, turning circle, and how much of the garage is left when the door comes down. Those are the figures this page leads with, and every number on it is the manufacturer's.
Key Numbers
Powertrain
One engine, one transmission, no options. The 2.0-liter turbo makes 200 horsepower and 221 lb-ft, and the torque arrives from 1,750 rpm.
| Engine | 2.0L I4 DOHC DI Turbo with Stop/Start |
| Horsepower | 200 hp at 5,000 rpm |
| Torque | 221 lb-ft from 1,750 to 4,250 rpm |
| Transmission | Eight-speed automatic |
| Drivetrain | Four-wheel drive, standard on all six trims |
| Fuel | Regular unleaded, 87 octane |
| Trailhawk final drive | 4.398, with a 20:1 crawl ratio; 3.73 on the other five trims |
Outside
At 173.4 inches the Compass parks in a standard stall with room to open a door, which is the practical difference between it and a mid-size SUV on Main Street in July.
| Length | 173.4 in |
| Width, excluding mirrors | 73.8 in |
| Height | 64.8 in |
| Wheelbase | 103.8 in |
| Track, front and rear | 60.7 in and 60.3 in |
| Ground clearance | 8.1 in; 8.6 in on the Trailhawk |
| Turning radius, curb to curb | 18.1 ft; 17.7 ft on the Trailhawk |
| Curb weight, Latitude through Limited Altitude | 3,620 pounds |
| Curb weight, Trailhawk | 3,840 pounds |
| GVWR | 4,800 pounds; 4,875 pounds on the Trailhawk |
| Approach, breakover, departure, Trailhawk | 30, 24 and 34 degrees |
| Water fording | 16 in; 19 in on the Trailhawk |
For payload, use the door-jamb label on the specific vehicle: that label is the rating that governs.
Inside
Passenger volume is 99.6 cubic feet across five seats, with 41.8 inches of front legroom and 38.3 inches in the second row.
| Measurement | Front | Rear |
|---|---|---|
| Headroom | 39.2 in without sunroof | 38.5 in |
| Legroom | 41.8 in | 38.3 in |
| Shoulder room | 56.7 in | 55.1 in |
| Hip room | 54.1 in | 49.2 in |
Capacity
Cargo runs 27.2 cubic feet behind the second row and 59.8 with that row down, and one configuration in the lineup carries a trailer rating.
| Cargo behind the second row | 27.2 cu ft |
| Cargo behind the first row, second row folded | 59.8 cu ft |
| Passenger volume | 99.6 cu ft |
| Load floor height | 29.7 in |
| Seating | Five, two front and three rear |
| Fuel tank | 13.5 gal |
| Maximum trailer weight | 2,000 pounds, properly equipped, on a conventional hitch behind the 2.0-liter turbo and Active Drive Low 4x4; the Trailer-Tow Group is orderable on the Trailhawk only and the other five trims carry no trailer rating |
Rolling Stock
Wheel diameter runs from 17 to 19 inches, and the tire is where the trims actually diverge: only the Trailhawk wears an all-terrain.
| Trim | Wheel | Tire |
|---|---|---|
| Latitude | 17-inch aluminum | 225/60R17 |
| Latitude Altitude | 18-inch gloss black aluminum | 225/55R18 |
| 85th Anniversary Edition | 19-inch Steel Oxide aluminum | 235/45R19 |
| Limited | 18-inch diamond-cut aluminum | 225/55R18 |
| Trailhawk | 17-inch painted black aluminum | 215/65R17 Falken WildPeak All-Terrain |
| Limited Altitude | 19-inch Satin Granite Crystal aluminum | 235/45R19 |
The Trailhawk carries a full-size spare as standard equipment.
Fuel
The EPA rates one configuration for 2026, "Compass 4WD," so the same 23/31/26 applies to every trim on the lot.
Range is the practical read on those numbers. A 13.5-gallon tank at 26 combined is a little over 350 miles, which covers a week of Barnstable errands, or a run up to Plymouth and back on the same tank. Most Cape Cod driving never troubles the second half of it. A Falmouth commuter will see the city figure more often than the highway one, because the Route 28 lights and the bridge approaches are where the stop-start actually lives, while a Marion or Plymouth commute is steadier and stretches the interval between fills. Barnstable and Falmouth drivers refuel at roughly the same rate; the off-Cape towns do better.
| EPA city | 23 MPG |
| EPA highway | 31 MPG |
| EPA combined | 26 MPG |
| Estimated annual fuel cost | $2,350 |
| Fuel tank | 13.5 gal of regular 87 octane |
EPA figures and the annual cost estimate are published at fueleconomy.gov.
Equipment Grid
The decision features, trim by trim. S is standard, O is available, and "not std" means the feature is not standard equipment on that trim.
| Feature | Lat | Lat Alt | 85th | Ltd | Trail | Ltd Alt |
|---|---|---|---|---|---|---|
| Four-wheel drive | S | S | S | S | S | S |
| Low range | not std | not std | not std | not std | S | not std |
| Heated front seats and steering wheel | S | S | S | S | S | S |
| Remote start | S | S | S | S | S | S |
| 10.1-inch touchscreen | not std | S | S | S | S | S |
| 10.25-inch digital cluster | not std | not std | not std | S | not std | S |
| Wireless Apple CarPlay and Android Auto | S | S | S | S | S | S |
| Adaptive cruise with stop and go | not std | not std | not std | S | S | S |
| Blind-spot monitoring | S | S | S | S | S | S |
| Active Driving Assist | not std | O | not std | not std | not std | O |
| Panoramic sunroof | not std | O | S | O | O | O |
| Power liftgate | not std | not std | not std | S | not std | S |
| Leatherette seats | not std | not std | not std | S | not std | S |
| Roof rails | S | S | S | S | S | S |
Ratings
NHTSA rates the 2026 Compass at four stars overall. The IIHS results are mixed, and both bodies publish the full breakdown.
| NHTSA overall | Four stars |
| IIHS small overlap front, driver side | Good |
| IIHS small overlap front, passenger side | Good |
| IIHS moderate overlap front, updated | Poor |
| IIHS side, updated | Marginal |
| IIHS headlights | Acceptable |
| Airbags | Seven, standard |
Ratings are published at nhtsa.gov and iihs.org. The full list of standard driver aids is on the technology and safety page.
Coverage
Basic coverage runs three years or 36,000 miles, and the powertrain and roadside terms both run five years or 60,000 miles.
| Basic limited warranty | 3 years or 36,000 miles |
| Powertrain limited warranty | 5 years or 60,000 miles |
| Roadside assistance | 5 years or 60,000 miles |
| Corrosion, sheet metal panels | 3 years, unlimited miles |
| Corrosion, outer body panels | 5 years, unlimited miles |
In Practice
Four figures on this page do most of the work in a real week, and none of them is the horsepower.
173.4 inches and an 18.1-foot turning circle. That combination is what lets the car turn around on a two-lane without a three-point and slot into an angled space on Route 132 or along Route 28 that a mid-size SUV has to pass. It is also meaningfully shorter than a Cherokee, which is often the difference between the garage door closing and not.
73.8 inches across the body. Measure the opening you actually park in against that figure plus your mirrors, because mirrors are what catch a carport post or a garage jamb, and they catch first.
13.5 gallons at 26 MPG combined (fueleconomy.gov). Call it a small tank on a car that does not drink much. It is the number to know before assuming a round trip down to Dartmouth and back, or an off-season run out Route 6 to the tip, is a one-fill errand in February with the heat running.
8.1 inches of clearance and 16 inches of fording. Read those as unplowed snow, a flooded dip near Hyannis Harbor after a spring tide, and the rutted sand approach to a lot like Kalmus Beach in the off season. The Trailhawk's 8.6 and 19 inches move the same needle further without turning the car into something else.
Questions
173.4 inches, on a 103.8-inch wheelbase. It is 73.8 inches wide excluding mirrors and 64.8 inches tall.
3,620 pounds on the Latitude through the Limited Altitude, and 3,840 pounds on the Trailhawk, which carries the heavier driveline, skid plates and a full-size spare. GVWR is 4,800 pounds, or 4,875 on the Trailhawk.
8.1 inches on five trims and 8.6 inches on the Trailhawk, which rides on an off-road tuned suspension with increased ride height.
13.5 gallons of regular 87 octane. At the EPA combined rating of 26 MPG that is a small tank on an efficient engine, so plan longer trips around a fill rather than around the rating.
Use the door-jamb label on the vehicle you are buying. That label carries the payload rating for that exact build, including its options, and it is the figure to work from.
The Trailhawk carries a full-size spare as standard equipment. It is the only trim that does.
27.2 cubic feet. Folding the second row opens 59.8 cubic feet behind the first row, and the load floor sits 29.7 inches off the ground.
